VMR Series

Specifications

Dimension and weight

-

Maximum load: 30kg

-

Model number: VMR-1000

-

Material: Steel + Aluminum alloy + Plastic

Surface treatment: Pickling and phosphating + electrostatic spraying, anti-corrosion and anti-rust

-

Detailed size & net weight

1150 (L) x 740 (D), 41Kg

2160 (H) max

-

Aluminum tube height adjustment: 350mm

Adjust spacing: 50mm per gear

-

Packing gross weight

1180 (L) x 740 (W) x 120 (H)

-

Specifications of inner and outer tubes:

Outer tube: 150*100 special-shaped aluminum tube

Inner tube: 125*78 special-shaped aluminum tube

NOTE: Specifications are correct as of the date of publication but may subjected to changes without further notice. Please clarify with us or our local representatives before making any purchase.

-

Projector mounting plate: Iron parts, 498 (L) x 380 (W)

-

Projector mounting plate front and rear adjustment distance: 300mm

-

Projector mounting plate height from the ground: 260mm-460mm (the support height is adjusted through the upper screw rod of the support foot)

-

Connection method between outer tube and chassis: Bolted

-

Cart movement method: The base is equipped with 4 casters with brakes, and the supporting feet are equipped with casters.

-

ALR Screen installation: Adapt to various forms of ALR Screen installation by installing mounting holes on the cross beams and using small hanging boards or hooks.

-

Suitable for screen size: 80 - 120 inch
